| Manufacturer: | Allen Bradley - Drives |
| Product Type: | Drive |
| Part Number: | 1336F-B030-AA-EN-GM1-HAS1-L4 |
| Series: | 1336F |
Description:
This is the Allen-Bradley 1336F-B030-AA-EN-GM1-HAS1-L4 adjustable frequency drive. This three phase drive is included in the 1336 Plus II series of drives that are compatible with industrial three phase motors. This drive has an output power rating of 22 Kilowatts (30 Horsepower) and has an input voltage range of 380 to 480 Volts AC. The drive comes preinstalled with a Remote I/O panel, a TTL Contact control interface, and an integrated HIM. It is housed in a NEMA Type 1 IP20 specification enclosure.
Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.
Pay
We accept credit cards from all major providers, as well as PayPal.
Ship
We offer worldwide shipping with UPS and DHL.
Warranty
We proudly offer a one year Automation Stop warranty on most products.
Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
The 1336F-B030-AA-EN-GM1-HAS1-L4 is a three phase drive made by Allen-Bradley. It is part of the 1336 Plus II series of adjustable frequency drives and operates on an input voltage range of 380 to 480 Volts AC. The drive is rated for a nominal power output of 22 Kilowatts (30 Horsepower). This model comes with a Single Point Remote I/O B Frame that provides enhanced connectivity options. The Remote I/O capability allows control of the drive logic and speed reference commands as well as monitoring drive status. The panel is compatible with RS232/422/485, DF1 & DH485 Protocols and can connect to devices on DeviceNet and Enhanced DeviceNet networks. A Human Interface Module (HIM) is also built-in that provides a Programmer and Controller panel with an analog potentiometer. Control Interface options include a TTL Contact Closure Interface Board. The board is compatible with contacts running at 10 milliamperes without signal degradation. The component is designed to be compatible with PLC models 1771-OYL and 1771-OZL. The interface board does not include encoder feedback terminals. The drive has a total power dissipation rating of 961 Watts. This module is housed in a NEMA Type 1 enclosure that is built to meet IP20 standards for protecting the components from environmental contaminants. This unit has an approximate shipping weight of 50 pounds (22.7 kilograms) and has dimensions of 10.88 x 18.75 x 8.86 inches (276.4 x 476.3 x 225.0 millimeters). When mounting the drive, care must be taken to ensure at least 6 inches of clearance above and below the drive and 4 inches of clearance on the sides in order to ensure adequate ventilation.
Technical Specifications
| MPN | 1336F-B030-AA-EN-GM1-HAS1-L4 |
| Manufacturer | Allen Bradley/Rockwell Automation |
| Series | 1336 PLUS II Adjustable Frequency AC Drive |
| Voltage | 380-480V AC |
| kW | 22 |
| HP | 30 |
| Enclosure Type | IP 20 (NEMA 1) |
| Language | English |
| Human Interface Module, Snap-In, IP20 | Programmer/Controller w/Analog Pot |
| Communication Options - B Frame & Up | Single Point Remote I/O B Frame |
| Control Interface Options | TTL Contact |
| Frame | B1/B2 |
FAQ
Question: Does Automation Stop offer repairs on the 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: Yes. We offer repairs for the 1336F-B030-AA-EN-GM1-HAS1-L4 and it comes with our 1 Year Automation Stop Warranty.
Question: What type of warranty comes with the Allen Bradley - Drives and 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: If you buy the 1336F-B030-AA-EN-GM1-HAS1-L4 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.
Question: Can I buy the 1336F-B030-AA-EN-GM1-HAS1-L4 online?
Answer: Yes. Automation Stop sells the 1336F-B030-AA-EN-GM1-HAS1-L4 online and you can check out for the quantity and condition listed available above.
Question: What is the manufacturer for the 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: The 1336F-B030-AA-EN-GM1-HAS1-L4 is made by Allen Bradley - Drives.
Question: What Communication Options - B Frame & Up does the 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The 1336F-B030-AA-EN-GM1-HAS1-L4 has a Single Point remote i/o B Frame Communication Options - B Frame & Up.
Question: What kind of Control Interface Options does the 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The Allen Bradley-Rockwell Automation 1336F-B030-AA-EN-GM1-HAS1-L4 has Control Interface Options TTL Contact.
Question: What Enclosure Type does the Allen Bradley Automation 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The Enclosure Type of the 1336F-B030-AA-EN-GM1-HAS1-L4 is IP 20 (NEMA 1).
Question: What Frame does the 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The Frame of the 1336F-B030-AA-EN-GM1-HAS1-L4 is B1/B2.
Question: What is the HP of the 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: The HP of the Allen Bradley 1336F-B030-AA-EN-GM1-HAS1-L4 is 30.
Question: What Human Interface Module, Snap-In, IP20 does the Allen Bradley 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The Allen Bradley 1336F-B030-AA-EN-GM1-HAS1-L4 has a Programmer/Controller w/Analog Pot Human Interface Module, Snap-In, IP20.
Question: What is the kW of the 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: The kW of the 1336F-B030-AA-EN-GM1-HAS1-L4 is 22.
Question: What Language does the 1336F-B030-AA-EN-GM1-HAS1-L4 have?
Answer: The Rockwell-Automation 1336F-B030-AA-EN-GM1-HAS1-L4 has a English Language.
Question: What is the Voltage of the 1336F-B030-AA-EN-GM1-HAS1-L4?
Answer: The 1336F-B030-AA-EN-GM1-HAS1-L4 has a Voltage of 380-480 volts AC (alternating current).
Series information for 1336F-B030-AA-EN-GM1-HAS1-L4
For additional information about 1336F-B030-AA-EN-GM1-HAS1-L4 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding 1336F-B030-AA-EN-GM1-HAS1-L4.
| Revision Part # | Also Known As | Availability |
|---|---|---|
| 1336F-B030-AA-EN-GM1-HAS1-L4/A | 1336F-B030-AA-EN-GM1-HAS1-L4 Ser A, Series A, Rev A | Request a Quote |
