Emerson - GE Fanuc IC200UEX616

✓ In Stock

IC200UEX616 Image 1 thumbnail
IC200UEX616 Image 2 thumbnail
IC200UEX616 Image 3 thumbnail
IC200UEX616 Image 4 thumbnail
IC200UEX616 Image 5 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC200UEX616
Series: Versamax Micro
UPC: 445979572286

Description:

The IC200UEX616 is a 6 Analog Expansion unit for VersaMax Micro PLC devices. The six analog channels of this device are divided into four (4) analog input channels and two (2) analog output channels. The rated power supply source is 12 volts DC. The resolution of the input and output channels is 12-bit. The input power supply rating is 2.25 watts, and the voltage range of this device is 9.6 volts DC to 15 volts DC.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Part number IC200UEX616, which was designed and manufactured by Emerson - GE Fanuc, is a VersaMax Micro PLC analog expansion unit. This unit has a rated power supply of 12 volts direct current (DC) This device is equipped with a total of six (6) analog channels, in which four (4) of these channels are analog in while the remaining two (2) are analog out. The analog input ranges of this device include: 0 to 10 volts with a maximum of 10.23 volts, -10 volts to +10 volts with a minimum of 10.23 volts and a maximum of +10.23 volts, 0 to 20 milliamperes with a maximum of 20.47 milliamperes, and 4 to 20 milliamperes with a maximum of 20.47 milliamperes. The analog output ranges of this device include: 0 to 10 volts with a maximum of 10.24 volts, 0 to 20 milliamperes with a maximum of 20.47 milliamperes, and 4 to 20 milliamperes with a maximum of 20.5 milliamperes. This device has a resolution of 12 bits for both analog inputs and analog outputs.

The Emerson - GE Fanuc IC200UEX616 has a voltage range of 9.6 volts DC to 15 volts DC with a hold-up time of 10.1 milliseconds at the voltage of 9.6 volts. This device has an in-rush time of 1 millisecond at 15 volts. The in-rush current is 0.9 amperes at 15 volts, and the input current at this voltage is 0.15 amperes. The input power supply rating of this product is 2.25 watts. The physical dimensions of this device measure 90 mm x 150 mm x 90 mm (height x width x depth).

We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC200UEX616?

Answer: Yes. We offer repairs for the IC200UEX616 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC200UEX616?

Answer: If you buy the IC200UEX616 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC200UEX616 online?

Answer: Yes. Automation Stop sells the IC200UEX616 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC200UEX616?

Answer: The IC200UEX616 is made by Emerson - GE Fanuc.


Series information for IC200UEX616

For additional information about IC200UEX616 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC200UEX616.

Revision Part # Also Known As Availability
IC200UEX616B IC200UEX616 Series B, Rev B Request a Quote
IC200UEX616D IC200UEX616 Series D, Rev D Request a Quote
